Evening all,
It’s certainly been a while since I last had a look around here - following a change of workplace the idealised use case for my Pocket unfortunately didn’t come to pass (can’t connect personal devices to corporate assets, even for serial console work) but I’ve dusted off the cobwebs and fired it back up this week for some tinkering in my off time.
I completed the recent firmware updates (up to 20260819) ahead of a reimage (I was still on the (pre-GNOME, I think?) 2024 system image) and since then have been faced with an inactive display at (what would be) the LUKS prompt at boot. Entering the passphrase blind continues the boot process and brings the display to life, but no matter what I do I can’t get the pre-decryption prompt to display even after installing the latest system image afresh. It’s not a blank display - the panel itself doesn’t illuminate whatsoever.
Log output from a normal boot is as follows:
I: Contents of /proc/device-tree/model: MNT Pocket Reform with i.MX8MP Module
I: `uname -a` output: Linux cyclone 7.1.10-mnt-reform-arm64 #1 SMP PREEMPT Debian 7.1.10-1+reform20260826T130932Z (2026-08-2 aarch64 GNU/Linux
I: Version of linux-image-mnt-reform-arm64: 7.1.10-1+reform20260826T130932Z
I: Version of reform-tools: 1.88-1+reform20260817T102547Z+1
I: Version of system image: System Image v5: 2026-08-13
I: Version of system controller firmware: 20260819
I: Version of keyboard firmware: 20260819
W: No known path for mnt_pocket_reform_panel_version for MNT Pocket Reform with i.MX8MP Module -- please consider contributing the output of: find /sys -name mnt_pocket_reform_panel_version
W: /sys/bus/spi/drivers/reform2_lpc/spi1.0/firmware does not exist -- is the reform2_lpc module loaded?
I: Version of upstream U-Boot: 2022.04
I: Version of MNT U-Boot: 2026-01-28
I: probably booting via /boot/extlinux/extlinux.conf (/boot/boot.scr also exists)
I: Mount source of /: /dev/reformvg/root (LVM vg 'reformvg' on LUKS device 'reform_crypt' on SSD)
I: Mount source of /boot: /dev/mmcblk2p1 (eMMC)
I: the following files differ from how they are shipped by reform-tools (ignore /var/lib/alsa/asound.state):
??5?????? /var/lib/alsa/asound.state
I: kernel boot parameters your system does use but which are not the default:
+ console=ttymxc1,115200
I: kernel boot parameters which are the default but your system doesn't use them:
- console=ttymxc1
E: Failed to fetch https://source.mnt.re/reform/reform-imx8mp-uboot/-/jobs/artifacts/2026-01-28/raw/imx8mp-mnt-pocket-reform-flash.bin?job=build Unable to connect to source.mnt.re:https:
E: Download Failed
E: download of https://source.mnt.re/reform/reform-imx8mp-uboot/-/jobs/artifacts/2026-01-28/raw/imx8mp-mnt-pocket-reform-flash.bin?job=build failed
As it asked so nicely, find /sys -name mnt_pocket_reform_panel_version returns:
/sys/devices/platform/soc@0/32c00000.bus/32e60000.dsi/32e60000.dsi.0/mnt_pocket_reform_panel_version.
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[ 0.000000] Linux version 7.1.10-mnt-reform-arm64 (debian-kernel@lists.debian.org) (aarch64-linux-gnu-gcc-15 (Debian 15.3.0-2) 15.3.0, GNU ld (GNU Binutils for Debian) 2.47) #1 SMP PREEMPT Debian 7.1.10-1+reform20260826T130932Z (2026-08-2
[ 0.000000] KASLR disabled due to lack of seed
[ 0.000000] Machine model: MNT Pocket Reform with i.MX8MP Module
[ 0.000000] efi: UEFI not found.
[ 0.000000] OF: reserved mem: 0x0000000057e00000..0x0000000057ffffff (2048 KiB) nomap non-reusable optee_shm@57e00000
[ 0.000000] OF: reserved mem: 0x0000000056000000..0x0000000057dfffff (30720 KiB) nomap non-reusable optee_core@56000000
[ 0.000000] NUMA: Faking a node at [mem 0x0000000040000000-0x000000023fffffff]
[ 0.000000] NODE_DATA(0) allocated [mem 0x23efc0280-0x23efc3a7f]
[ 0.000000] cma: Reserved 256 MiB at 0x00000000f0000000
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.1 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: Trusted OS migration not required
[ 0.000000] psci: SMC Calling Convention v1.2
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000040000000-0x00000000ffffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal [mem 0x0000000100000000-0x000000023fffffff]
[ 0.000000] Device empty
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000040000000-0x0000000055ffffff]
[ 0.000000] node 0: [mem 0x0000000058000000-0x000000023fffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000040000000-0x000000023fffffff]
[ 0.000000] On node 0, zone DMA: 8192 pages in unavailable ranges
[ 0.000000] percpu: Embedded 36 pages/cpu s108056 r8192 d31208 u147456
[ 0.000000] pcpu-alloc: s108056 r8192 d31208 u147456 alloc=36*4096
[ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] CPU features: detected: GICv3 CPU interface
[ 0.000000] CPU features: detected: ARM erratum 845719
[ 0.000000] alternatives: applying boot alternatives
[ 0.000000] Kernel command line: ro no_console_suspend cryptomgr.notests plymouth.ignore-serial-consoles pcie_aspm=off ro no_console_suspend pci=pcie_bus_perf nvme_core.default_ps_max_latency_us=0 console=ttymxc1,115200 console=tty1 fbcon=font:TER16x32 cma=256MB console=tty1
[ 0.000000] PCIe ASPM is disabled
[ 0.000000] printk: log buffer data + meta data: 131072 + 557056 = 688128 bytes
[ 0.000000] Dentry cache hash table entries: 1048576 (order: 11, 8388608 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 524288 (order: 10, 4194304 bytes, linear)
[ 0.000000] software IO TLB: area num 4.
[ 0.000000] software IO TLB: mapped [mem 0x00000000ec000000-0x00000000f0000000] (64MB)
[ 0.000000] Fallback order for Node 0: 0
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 2088960
[ 0.000000] Policy zone: Normal
[ 0.000000] mem auto-init: stack:all(zero), heap alloc:on, heap free:off
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] ftrace: allocating 55412 entries in 218 pages
[ 0.000000] ftrace: allocated 218 pages with 5 groups
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] rcu: RCU restricting CPUs from NR_CPUS=512 to nr_cpu_ids=4.
[ 0.000000] Trampoline variant of Tasks RCU enabled.
[ 0.000000] Rude variant of Tasks RCU enabled.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 25 jiffies.
[ 0.000000] rcu: Adjusting geometry for rcu_fanout_leaf=16, nr_cpu_ids=4
[ 0.000000] RCU Tasks: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.000000] RCU Tasks Rude: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode
[ 0.000000] GICv3: 160 SPIs implemented
[ 0.000000] GICv3: 0 Extended SPIs implemented
[ 0.000000] Root IRQ handler: gic_handle_irq
[ 0.000000] GICv3: GICv3 features: 16 PPIs
[ 0.000000] GICv3: GICD_CTLR.DS=0, SCR_EL3.FIQ=1
[ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x0000000038880000
[ 0.000000] ITS: No ITS available, not enabling LPIs
[ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[ 0.000000] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns
[ 0.000000] arch_timer: cp15 timer running at 8.00MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x1d854df40, max_idle_ns: 440795202120 ns
[ 0.000000] sched_clock: 56 bits at 8MHz, resolution 125ns, wraps every 2199023255500ns
[ 0.001672] Console: colour dummy device 80x25
[ 0.001685] printk: legacy console [tty1] enabled
[ 0.003069] Calibrating delay loop (skipped), value calculated using timer frequency.. 16.00 BogoMIPS (lpj=32000)
[ 0.003097] pid_max: default: 32768 minimum: 301
[ 0.006177] landlock: Up and running.
[ 0.006193] Yama: disabled by default; enable with sysctl kernel.yama.*
[ 0.006488] AppArmor: AppArmor initialized
[ 0.006556] TOMOYO Linux initialized
[ 0.006990] LSM support for eBPF active
[ 0.008582] Mount-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.008621] Mountpoint-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.009959] VFS: Finished mounting rootfs on nullfs
[ 0.015779] rcu: Hierarchical SRCU implementation.
[ 0.015811] rcu: Max phase no-delay instances is 1000.
[ 0.016136] Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level
[ 0.019720] EFI services will not be available.
[ 0.020253] smp: Bringing up secondary CPUs ...
[ 0.020992] Detected VIPT I-cache on CPU1
[ 0.021118] GICv3: CPU1: found redistributor 1 region 0:0x00000000388a0000
[ 0.021160] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[ 0.022024] Detected VIPT I-cache on CPU2
[ 0.022140] GICv3: CPU2: found redistributor 2 region 0:0x00000000388c0000
[ 0.022170] CPU2: Booted secondary processor 0x0000000002 [0x410fd034]
[ 0.023037] Detected VIPT I-cache on CPU3
[ 0.023150] GICv3: CPU3: found redistributor 3 region 0:0x00000000388e0000
[ 0.023180] CPU3: Booted secondary processor 0x0000000003 [0x410fd034]
[ 0.023300] smp: Brought up 1 node, 4 CPUs
[ 0.023400] SMP: Total of 4 processors activated.
[ 0.023414] CPU: All CPU(s) started at EL2
[ 0.023454] CPU features: detected: 32-bit EL0 Support
[ 0.023467] CPU features: detected: 32-bit EL1 Support
[ 0.023484] CPU features: detected: CRC32 instructions
[ 0.023506] CPU features: detected: PMUv3
[ 0.023565] alternatives: applying system-wide alternatives
[ 0.072013] node 0 deferred pages initialised in 44ms
[ 0.072136] Memory: 7781828K/8355840K available (18816K kernel code, 5154K rwdata, 11432K rodata, 3776K init, 913K bss, 306624K reserved, 262144K cma-reserved)
[ 0.074138] devtmpfs: initialized
[ 0.092231] posixtimers hash table entries: 2048 (order: 3, 32768 bytes, linear)
[ 0.092334] futex hash table entries: 1024 (65536 bytes on 1 NUMA nodes, total 64 KiB, linear).
[ 0.097077] 22688 pages in range for non-PLT usage
[ 0.097099] 514208 pages in range for PLT usage
[ 0.103188] DMI: not present or invalid.
[ 0.106376] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[ 0.107952] DMA: preallocated 1024 KiB GFP_KERNEL pool for atomic allocations
[ 0.108291] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.108360] audit: initializing netlink subsys (disabled)
[ 0.108550] audit: type=2000 audit(0.104:1): state=initialized audit_enabled=0 res=1
[ 0.111692] thermal_sys: Registered thermal governor 'fair_share'
[ 0.111707] thermal_sys: Registered thermal governor 'bang_bang'
[ 0.111729] thermal_sys: Registered thermal governor 'step_wise'
[ 0.111745] thermal_sys: Registered thermal governor 'user_space'
[ 0.111758] thermal_sys: Registered thermal governor 'power_allocator'
[ 0.111827] cpuidle: using governor ladder
[ 0.111878] cpuidle: using governor menu
[ 0.112283] hw-breakpoint: found 6 breakpoint and 4 watchpoint registers.
[ 0.112418] ASID allocator initialised with 65536 entries
[ 0.114669] Serial: AMBA PL011 UART driver
[ 0.124071] /soc@0: Fixed dependency cycle(s) with /soc@0/bus@30000000/efuse@30350000/unique-id@8
[ 0.124188] /soc@0/etm@28440000: Fixed dependency cycle(s) with /funnel
[ 0.124375] /soc@0/etm@28540000: Fixed dependency cycle(s) with /funnel
[ 0.124454] /soc@0/etm@28640000: Fixed dependency cycle(s) with /funnel
[ 0.124531] /soc@0/etm@28740000: Fixed dependency cycle(s) with /funnel
[ 0.124580] /soc@0/funnel@28c03000: Fixed dependency cycle(s) with /soc@0/etf@28c04000
[ 0.124634] /soc@0/funnel@28c03000: Fixed dependency cycle(s) with /funnel
[ 0.124681] /soc@0/etf@28c04000: Fixed dependency cycle(s) with /soc@0/etr@28c06000
[ 0.124740] /soc@0/etf@28c04000: Fixed dependency cycle(s) with /soc@0/funnel@28c03000
[ 0.124819] /soc@0/etr@28c06000: Fixed dependency cycle(s) with /soc@0/etf@28c04000
[ 0.125834] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000/panel@0
[ 0.125916] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32e80000
[ 0.126070] /soc@0/bus@32c00000/dsi@32e60000/panel@0: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.126174] /soc@0/bus@32c00000/display-controller@32e80000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.126506] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/hdmi@32fd8000
[ 0.126631] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32fc6000
[ 0.126878] /soc@0/bus@32c00000/display-controller@32fc6000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.127166] /soc@0/bus@32c00000/hdmi@32fd8000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.127602] /soc@0/interrupt-controller@38800000: Fixed dependency cycle(s) with /soc@0/interrupt-controller@38800000
[ 0.128353] /funnel: Fixed dependency cycle(s) with /soc@0/etm@28440000
[ 0.128485] /soc@0/etm@28440000: Fixed dependency cycle(s) with /funnel
[ 0.128715] /funnel: Fixed dependency cycle(s) with /soc@0/etm@28540000
[ 0.128865] /soc@0/etm@28540000: Fixed dependency cycle(s) with /funnel
[ 0.129068] /funnel: Fixed dependency cycle(s) with /soc@0/etm@28640000
[ 0.129224] /soc@0/etm@28640000: Fixed dependency cycle(s) with /funnel
[ 0.129421] /funnel: Fixed dependency cycle(s) with /soc@0/etm@28740000
[ 0.129541] /soc@0/etm@28740000: Fixed dependency cycle(s) with /funnel
[ 0.129809] /funnel: Fixed dependency cycle(s) with /soc@0/funnel@28c03000
[ 0.129904] /soc@0/funnel@28c03000: Fixed dependency cycle(s) with /soc@0/etf@28c04000
[ 0.129968] /soc@0/funnel@28c03000: Fixed dependency cycle(s) with /funnel
[ 0.130202] /soc@0/funnel@28c03000: Fixed dependency cycle(s) with /soc@0/etf@28c04000
[ 0.130302] /soc@0/etf@28c04000: Fixed dependency cycle(s) with /soc@0/etr@28c06000
[ 0.130370] /soc@0/etf@28c04000: Fixed dependency cycle(s) with /soc@0/funnel@28c03000
[ 0.130581] /soc@0/etf@28c04000: Fixed dependency cycle(s) with /soc@0/etr@28c06000
[ 0.130716] /soc@0/etr@28c06000: Fixed dependency cycle(s) with /soc@0/etf@28c04000
[ 0.135966] imx8mp-pinctrl 30330000.pinctrl: initialized IMX pinctrl driver
[ 0.136789] /soc@0/bus@30000000/efuse@30350000: Fixed dependency cycle(s) with /soc@0/bus@30000000/clock-controller@30380000
[ 0.138295] /soc@0/bus@30000000/efuse@30350000: Fixed dependency cycle(s) with /soc@0/bus@30000000/clock-controller@30380000
[ 0.139703] /soc@0/bus@30000000/clock-controller@30380000: Fixed dependency cycle(s) with /soc@0/interrupt-controller@38800000
[ 0.154573] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000/panel@0
[ 0.154663] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32e80000
[ 0.154772] /soc@0/bus@32c00000/dsi@32e60000/panel@0: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.154919] /soc@0/bus@32c00000/display-controller@32e80000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.155297] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/hdmi@32fd8000
[ 0.155388] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32fc6000
[ 0.155546] /soc@0/bus@32c00000/display-controller@32fc6000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.155803] /soc@0/bus@32c00000/hdmi@32fd8000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.156688] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000/panel@0
[ 0.156759] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32e80000
[ 0.156956] /soc@0/bus@32c00000/dsi@32e60000/panel@0: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.157416] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32e80000
[ 0.157589] /soc@0/bus@32c00000/display-controller@32e80000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 0.160973] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/hdmi@32fd8000
[ 0.161081] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32fc6000
[ 0.161649] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-controller@32fc6000
[ 0.161832] /soc@0/bus@32c00000/display-controller@32fc6000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.162547] /soc@0/bus@32c00000/display-bridge@32fc4000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/hdmi@32fd8000
[ 0.162822] /soc@0/bus@32c00000/hdmi@32fd8000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/display-bridge@32fc4000
[ 0.182287] HugeTLB: registered 1.00 GiB page size, pre-allocated 0 pages
[ 0.182323] HugeTLB: 0 KiB vmemmap can be freed for a 1.00 GiB page
[ 0.182339] HugeTLB: registered 32.0 MiB page size, pre-allocated 0 pages
[ 0.182355] HugeTLB: 0 KiB vmemmap can be freed for a 32.0 MiB page
[ 0.182370] HugeTLB: registered 2.00 MiB page size, pre-allocated 0 pages
[ 0.182384] HugeTLB: 0 KiB vmemmap can be freed for a 2.00 MiB page
[ 0.182401] HugeTLB: registered 64.0 KiB page size, pre-allocated 0 pages
[ 0.182416] HugeTLB: 0 KiB vmemmap can be freed for a 64.0 KiB page
[ 0.192531] ACPI: Interpreter disabled.
[ 0.195651] iommu: Default domain type: Translated
[ 0.195688] iommu: DMA domain TLB invalidation policy: strict mode
[ 0.198901] pps_core: LinuxPPS API ver. 1 registered
[ 0.198934] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it>
[ 0.198963] PTP clock support registered
[ 0.199039] EDAC MC: Ver: 3.0.0
[ 0.199463] scmi_core: SCMI protocol bus registered
[ 0.201907] NetLabel: Initializing
[ 0.201936] NetLabel: domain hash size = 128
[ 0.201949] NetLabel: protocols = UNLABELED CIPSOv4 CALIPSO
[ 0.202037] NetLabel: unlabeled traffic allowed by default
[ 0.202314] vgaarb: loaded
[ 0.202889] clocksource: Switched to clocksource arch_sys_counter
[ 0.205433] VFS: Disk quotas dquot_6.6.0
[ 0.205584] VFS: Dquot-cache hash table entries: 512 (order 0, 4096 bytes)
[ 0.206670] AppArmor: AppArmor Filesystem Enabled
[ 0.206947] pnp: PnP ACPI: disabled
[ 0.217463] NET: Registered PF_INET protocol family
[ 0.217798] IP idents hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[ 0.224954] tcp_listen_portaddr_hash hash table entries: 4096 (order: 4, 65536 bytes, linear)
[ 0.225089] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[ 0.225188] TCP established hash table entries: 65536 (order: 7, 524288 bytes, linear)
[ 0.225872] TCP bind hash table entries: 65536 (order: 9, 2097152 bytes, linear)
[ 0.227834] TCP: Hash tables configured (established 65536 bind 65536)
[ 0.228319] MPTCP token hash table entries: 8192 (order: 6, 196608 bytes, linear)
[ 0.228759] UDP hash table entries: 4096 (order: 6, 262144 bytes, linear)
[ 0.229319] NET: Registered PF_UNIX/PF_LOCAL protocol family
[ 0.229386] NET: Registered PF_XDP protocol family
[ 0.229413] PCI: CLS 0 bytes, default 64
[ 0.229864] Trying to unpack rootfs image as initramfs...
[ 0.247773] kvm [1]: nv: 570 coarse grained trap handlers
[ 0.248130] kvm [1]: nv: 710 fine grained trap handlers
[ 0.248651] kvm [1]: IPA Size Limit: 40 bits
[ 0.251958] kvm [1]: GICv3: no GICV resource entry
[ 0.251991] kvm [1]: disabling GICv2 emulation
[ 0.252017] kvm [1]: GICv3 sysreg trapping enabled ([C], reduced performance)
[ 0.252054] kvm [1]: GIC system register CPU interface enabled
[ 0.252147] kvm [1]: vgic interrupt IRQ9
[ 0.252184] kvm [1]: Hyp nVHE mode initialized successfully
[ 0.261669] Initialise system trusted keyrings
[ 0.261787] Key type blacklist registered
[ 0.262991] workingset: timestamp_bits=42 (anon: 38) max_order=21 bucket_order=0 (anon: 0)
[ 0.268579] fuse: init (API version 7.45)
[ 0.269609] integrity: Platform Keyring initialized
[ 0.269677] integrity: Machine keyring initialized
[ 0.269769] Key type asymmetric registered
[ 0.269785] Asymmetric key parser 'x509' registered
[ 0.270044] alg: self-tests disabled
[ 0.270401] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 244)
[ 0.270634] io scheduler mq-deadline registered
[ 0.287296] ledtrig-cpu: registered to indicate activity on CPUs
[ 0.308735] SoC: i.MX8MP revision 1.1
[ 0.346404] Serial: 8250/16550 driver, 4 ports, IRQ sharing enabled
[ 0.351002] Serial: AMBA driver
[ 0.352792] 30860000.serial: ttymxc0 at MMIO 0x30860000 (irq = 15, base_baud = 5000000) is a IMX
[ 0.353339] serial serial0: tty port ttymxc0 registered
[ 0.354104] 30880000.serial: ttymxc2 at MMIO 0x30880000 (irq = 16, base_baud = 5000000) is a IMX
[ 0.355497] 30890000.serial: ttymxc1 at MMIO 0x30890000 (irq = 17, base_baud = 1500000) is a IMX
[ 0.355730] printk: console [ttymxc1] enabled
[ 0.363537] 30a60000.serial: ttymxc3 at MMIO 0x30a60000 (irq = 18, base_baud = 5000000) is a IMX
[ 0.365405] msm_serial: driver initialized
[ 0.366694] SuperH (H)SCI(F) driver initialized
[ 0.391547] mousedev: PS/2 mouse device common for all mice
[ 0.410753] SMCCC: SOC_ID: ARCH_SOC_ID not implemented, skipping ....
[ 0.432410] hw perfevents: enabled with armv8_cortex_a53 PMU driver, 7 (0,8000003f) counters available
[ 0.439912] NET: Registered PF_INET6 protocol family
[ 0.445190] Segment Routing with IPv6
[ 0.445237] RPL Segment Routing with IPv6
[ 0.445291] In-situ OAM (IOAM) with IPv6
[ 0.445362] mip6: Mobile IPv6
[ 0.445386] NET: Registered PF_PACKET protocol family
[ 0.446173] mpls_gso: MPLS GSO support
[ 0.464299] registered taskstats version 1
[ 0.464592] Loading compiled-in X.509 certificates
[ 1.186155] Freeing initrd memory: 39208K
[ 1.223455] Loaded X.509 cert 'Build time autogenerated kernel key: 8b2006700667e03d8095ff82716c42a8a802b4e5'
[ 1.241017] Demotion targets for Node 0: null
[ 1.242027] Key type .fscrypt registered
[ 1.242050] Key type fscrypt-provisioning registered
[ 1.310116] Key type encrypted registered
[ 1.310168] AppArmor: AppArmor sha256 policy hashing enabled
[ 1.310193] ima: No TPM chip found, activating TPM-bypass!
[ 1.310210] ima: Allocated hash algorithm: sha256
[ 1.310363] ima: No architecture policies found
[ 1.310445] evm: Initialising EVM extended attributes:
[ 1.310459] evm: security.selinux
[ 1.310471] evm: security.SMACK64 (disabled)
[ 1.310487] evm: security.SMACK64EXEC (disabled)
[ 1.310499] evm: security.SMACK64TRANSMUTE (disabled)
[ 1.310513] evm: security.SMACK64MMAP (disabled)
[ 1.310528] evm: security.apparmor
[ 1.310541] evm: security.ima
[ 1.310551] evm: security.capability
[ 1.310567] evm: HMAC attrs: 0x1
[ 1.332141] gpio gpiochip0: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 1.334602] gpio gpiochip1: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 1.336978] gpio gpiochip2: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 1.339564] gpio gpiochip3: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 1.342047] gpio gpiochip4: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 1.371770] clk: Disabling unused clocks
[ 1.376663] PM: genpd: Disabling unused power domains
[ 1.386983] Freeing unused kernel memory: 3776K
[ 1.541230] Checked W+X mappings: passed, no W+X pages found
[ 1.541287] Run /init as init process
[ 1.541302] with arguments:
[ 1.541310] /init
[ 1.541319] with environment:
[ 1.541327] HOME=/
[ 1.541335] TERM=linux
[ 3.349916] cs_system_cfg: CoreSight Configuration manager initialised
[ 3.460083] imx8mq-usb-phy 381f0040.usb-phy: supply vbus not found, using dummy regulator
[ 3.460650] imx8mq-usb-phy 382f0040.usb-phy: supply vbus not found, using dummy regulator
[ 3.581567] /soc@0: Fixed dependency cycle(s) with /soc@0/bus@30000000/efuse@30350000
[ 3.638186] i2c i2c-0: using pinctrl states for GPIO recovery
[ 3.638331] i2c i2c-0: using generic GPIOs for recovery
[ 3.639201] i2c i2c-0: IMX I2C adapter registered
[ 3.639870] i2c i2c-1: using pinctrl states for GPIO recovery
[ 3.639967] i2c i2c-1: using generic GPIOs for recovery
[ 3.640167] i2c i2c-1: IMX I2C adapter registered
[ 3.640676] i2c i2c-2: using pinctrl states for GPIO recovery
[ 3.640743] i2c i2c-2: using generic GPIOs for recovery
[ 3.640978] imx-cpufreq-dt imx-cpufreq-dt: cpu speed grade 5 mkt segment 0 supported-hw 0x20 0x1
[ 3.641663] i2c i2c-2: IMX I2C adapter registered
[ 3.714868] sdhci-esdhc-imx 30b40000.mmc: Got CD GPIO
[ 3.718548] sdhci-esdhc-imx 30b40000.mmc: drop HS400 support since no 8-bit bus
[ 3.723093] sdhci-esdhc-imx 30b50000.mmc: drop HS400 support since no 8-bit bus
[ 3.742970] mmc2: SDHCI controller on 30b60000.mmc [30b60000.mmc] using ADMA
[ 3.751086] mmc0: SDHCI controller on 30b40000.mmc [30b40000.mmc] using ADMA
[ 3.825740] mmc1: SDHCI controller on 30b50000.mmc [30b50000.mmc] using ADMA
[ 3.842440] mmc2: new HS400 Enhanced strobe MMC card at address 0001
[ 3.875265] mmcblk2: mmc2:0001 X29128 117 GiB
[ 3.885298] mmcblk2: p1 p2
[ 3.917323] mmcblk2boot0: mmc2:0001 X29128 4.00 MiB
[ 3.927998] mmcblk2boot1: mmc2:0001 X29128 4.00 MiB
[ 3.935473] imx-sdma 30bd0000.dma-controller: loaded firmware 4.6
[ 3.947048] mmc1: queuing unknown CIS tuple 0x01 [d9 01 ff] (3 bytes)
[ 3.951799] imx6q-pcie 33800000.pcie: host bridge /soc@0/pcie@33800000 ranges:
[ 3.951880] imx6q-pcie 33800000.pcie: IO 0x001ff80000..0x001ff8ffff -> 0x0000000000
[ 3.951933] imx6q-pcie 33800000.pcie: MEM 0x0018000000..0x001fefffff -> 0x0018000000
[ 3.952035] imx6q-pcie 33800000.pcie: config reg[1] 0x1ff00000 == cpu 0x1ff00000
; no fixup was ever needed for this devicetree
[ 3.961686] imx-sdma 30e00000.dma-controller: loaded firmware 4.6
[ 3.991331] mmcblk2rpmb: mmc2:0001 X29128 4.00 MiB, chardev (238:0)
[ 4.012847] imx-sdma 30e10000.dma-controller: loaded firmware 4.6
[ 4.042478] mmc1: queuing unknown CIS tuple 0x1a [01 01 00 02 07] (5 bytes)
[ 4.053360] mmc1: queuing unknown CIS tuple 0x1b [c1 41 30 30 ff ff 32 00] (8 bytes)
[ 4.061632] mmc1: queuing unknown CIS tuple 0x14 [] (0 bytes)
[ 4.072008] mmc1: new UHS-I speed DDR50 SDIO card at address 0001
[ 4.159161] imx6q-pcie 33800000.pcie: iATU: unroll T, 4 ob, 4 ib, align 64K, limit 16G
[ 4.319411] rtc-pcf8523 2-0068: registered as rtc0
[ 4.325738] rtc-pcf8523 2-0068: setting system clock to 2026-08-26T18:52:53 UTC (1787770373)
[ 4.337527] nxp-pca9450 0-0025: PWRON interrupt.
[ 4.345400] nxp-pca9450 0-0025: pca9450bc probed.
[ 4.358940] imx6q-pcie 33800000.pcie: PCIe Gen.3 x1 link up
[ 4.359354] imx6q-pcie 33800000.pcie: PCI host bridge to bus 0000:00
[ 4.359391] pci_bus 0000:00: root bus resource [bus 00-ff]
[ 4.359404] pci_bus 0000:00: root bus resource [io 0x0000-0xffff]
[ 4.359415] pci_bus 0000:00: root bus resource [mem 0x18000000-0x1fefffff]
[ 4.359453] pci 0000:00:00.0: [16c3:abcd] type 01 class 0x060400 PCIe Root Port
[ 4.359474] pci 0000:00:00.0: BAR 0 [mem 0x00000000-0x000fffff]
[ 4.359485] pci 0000:00:00.0: ROM [mem 0x00000000-0x0000ffff pref]
[ 4.359496] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 4.359508] pci 0000:00:00.0: bridge window [io 0x0000-0x0fff]
[ 4.359518] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff]
[ 4.359530] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff pref]
[ 4.359569] pci 0000:00:00.0: supports D1
[ 4.359579] pci 0000:00:00.0: PME# supported from D0 D1 D3hot D3cold
[ 4.361756] pci 0000:01:00.0: [025e:f1ac] type 00 class 0x010802 PCIe Endpoint
[ 4.361884] pci 0000:01:00.0: BAR 0 [mem 0x00000000-0x00003fff 64bit]
[ 4.362331] pci 0000:01:00.0: 7.876 Gb/s available PCIe bandwidth, limited by 8.0 GT/s PCIe x1 link at 0000:00:00.0 (capable of 63.012 Gb/s with 16.0 GT/s PCIe x4 link)
[ 4.362638] pci 0000:00:00.0: BAR 0 [mem 0x18000000-0x180fffff]: assigned
[ 4.362666] pci 0000:00:00.0: bridge window [mem 0x18100000-0x181fffff]: assigned
[ 4.362679] pci 0000:00:00.0: ROM [mem 0x18200000-0x1820ffff pref]: assigned
[ 4.362694] pci 0000:01:00.0: BAR 0 [mem 0x18100000-0x18103fff 64bit]: assigned
[ 4.362727] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 4.362738] pci 0000:00:00.0: bridge window [mem 0x18100000-0x181fffff]
[ 4.362752] pci_bus 0000:00: resource 4 [io 0x0000-0xffff]
[ 4.362762] pci_bus 0000:00: resource 5 [mem 0x18000000-0x1fefffff]
[ 4.362773] pci_bus 0000:01: resource 1 [mem 0x18100000-0x181fffff]
[ 4.362790] pci 0000:00:00.0: Max Payload Size set to 128/ 128 (was 128), Max Read Rq 128
[ 4.362827] pci 0000:01:00.0: Max Payload Size set to 128/ 512 (was 128), Max Read Rq 128
[ 4.363273] pcieport 0000:00:00.0: PME: Signaling with IRQ 206
[ 4.364054] pcieport 0000:00:00.0: AER: enabled with IRQ 206
[ 4.444607] samsung-dsim 32e60000.dsi: supply vddcore not found, using dummy regulator
[ 4.444774] samsung-dsim 32e60000.dsi: supply vddio not found, using dummy regulator
[ 4.451312] /soc@0/bus@32c00000/dsi@32e60000: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000/panel@0
[ 4.451444] /soc@0/bus@32c00000/dsi@32e60000/panel@0: Fixed dependency cycle(s) with /soc@0/bus@32c00000/dsi@32e60000
[ 4.502133] usbcore: registered new interface driver usbfs
[ 4.502192] usbcore: registered new interface driver hub
[ 4.502246] usbcore: registered new device driver usb
[ 4.536407] imx-dwmac 30bf0000.ethernet: IRQ sfty not found
[ 4.544336] imx-dwmac 30bf0000.ethernet: User ID: 0x10, Synopsys ID: 0x51
[ 4.544376] imx-dwmac 30bf0000.ethernet: DWMAC4/5
[ 4.544388] imx-dwmac 30bf0000.ethernet: DMA HW capability register supported
[ 4.544401] imx-dwmac 30bf0000.ethernet: Active PHY interface: RGMII (1)
[ 4.544411] imx-dwmac 30bf0000.ethernet: RX Checksum Offload Engine supported
[ 4.544421] imx-dwmac 30bf0000.ethernet: TX Checksum insertion supported
[ 4.544432] imx-dwmac 30bf0000.ethernet: Wake-Up On Lan supported
[ 4.544548] imx-dwmac 30bf0000.ethernet: Enable RX Mitigation via HW Watchdog Timer
[ 4.544571] imx-dwmac 30bf0000.ethernet: device MAC address 56:b4:07:f9:d9:e6
[ 4.544586] imx-dwmac 30bf0000.ethernet: Enabled L3L4 Flow TC (entries=8)
[ 4.544597] imx-dwmac 30bf0000.ethernet: Enabled RFS Flow TC (entries=10)
[ 4.544614] imx-dwmac 30bf0000.ethernet: Enabling HW TC (entries=256, max_off=256)
[ 4.544627] imx-dwmac 30bf0000.ethernet: Using 34/40 bits DMA host/device width
[ 4.545057] mdio_bus stmmac-1: ethernet-phy has invalid PHY address
[ 4.545070] mdio_bus stmmac-1: scan phy ethernet-phy at address 0
[ 4.554937] mdio_bus stmmac-1: scan phy ethernet-phy at address 1
[ 4.558114] mdio_bus stmmac-1: scan phy ethernet-phy at address 2
[ 4.558913] mdio_bus stmmac-1: scan phy ethernet-phy at address 3
[ 4.564491] mdio_bus stmmac-1: scan phy ethernet-phy at address 4
[ 4.571655] mdio_bus stmmac-1: scan phy ethernet-phy at address 5
[ 4.575429] mdio_bus stmmac-1: scan phy ethernet-phy at address 6
[ 4.590097] mdio_bus stmmac-1: scan phy ethernet-phy at address 7
[ 4.676750] Key type psk registered
[ 4.721396] imx8mp-dw-hdmi-tx 32fd8000.hdmi: Detected HDMI TX controller v2.13a with HDCP (SAMSUNG HDMI TX PHY)
[ 4.722075] imx8mp-dw-hdmi-tx 32fd8000.hdmi: registered DesignWare HDMI I2C bus driver
[ 4.746396] imx-dwmac 30bf0000.ethernet end1: renamed from eth0
[ 4.759192] nvme nvme0: pci function 0000:01:00.0
[ 4.759234] nvme 0000:01:00.0: enabling device (0000 -> 0002)
[ 4.769057] Registered IR keymap rc-cec
[ 4.769242] rc rc0: dw_hdmi as /devices/platform/soc@0/32c00000.bus/32fd8000.hdmi/rc/rc0
[ 4.769388] input: dw_hdmi as /devices/platform/soc@0/32c00000.bus/32fd8000.hdmi/rc/rc0/input0
[ 4.800773] hwmon hwmon2: temp1_input not attached to any thermal zone
[ 4.800813] hwmon hwmon2: temp2_input not attached to any thermal zone
[ 4.800831] hwmon hwmon2: temp3_input not attached to any thermal zone
[ 4.800844] nvme nvme0: passthrough uses implicit buffer lengths
[ 4.854315] nvme nvme0: 4/0/0 default/read/poll queues
[ 4.946583] xhci-hcd xhci-hcd.0.auto: xHCI Host Controller
[ 4.946657] xhci-hcd xhci-hcd.0.auto: new USB bus registered, assigned bus number 1
[ 4.947035] xhci-hcd xhci-hcd.0.auto: hcc params 0x0220fe65 hci version 0x110 quirks 0x000080a001000010
[ 4.947096] xhci-hcd xhci-hcd.0.auto: irq 210, io mem 0x38100000
[ 4.947300] xhci-hcd xhci-hcd.0.auto: xHCI Host Controller
[ 4.947318] xhci-hcd xhci-hcd.0.auto: new USB bus registered, assigned bus number 2
[ 4.947341] xhci-hcd xhci-hcd.0.auto: Host supports USB 3.0 SuperSpeed
[ 4.947611] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 7.01
[ 4.947626] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 4.947640] usb usb1: Product: xHCI Host Controller
[ 4.947650] usb usb1: Manufacturer: Linux 7.1.10-mnt-reform-arm64 xhci-hcd
[ 4.947662] usb usb1: SerialNumber: xhci-hcd.0.auto
[ 4.948174] hub 1-0:1.0: USB hub found
[ 4.948226] hub 1-0:1.0: 1 port detected
[ 4.948774] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 4.948945] usb usb2: New USB device found, idVendor=1d6b, idProduct=0003, bcdDevice= 7.01
[ 4.948962] usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 4.948974] usb usb2: Product: xHCI Host Controller
[ 4.948983] usb usb2: Manufacturer: Linux 7.1.10-mnt-reform-arm64 xhci-hcd
[ 4.948993] usb usb2: SerialNumber: xhci-hcd.0.auto
[ 4.949551] hub 2-0:1.0: USB hub found
[ 4.949618] hub 2-0:1.0: 1 port detected
[ 4.950205] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 4.950246] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 3
[ 4.950601] xhci-hcd xhci-hcd.1.auto: hcc params 0x0220fe65 hci version 0x110 quirks 0x000080a001000010
[ 4.950686] xhci-hcd xhci-hcd.1.auto: irq 211, io mem 0x38200000
[ 4.950840] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 4.950858] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 4
[ 4.950920] xhci-hcd xhci-hcd.1.auto: Host supports USB 3.0 SuperSpeed
[ 4.951138] usb usb3: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 7.01
[ 4.951156] usb usb3: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 4.951168] usb usb3: Product: xHCI Host Controller
[ 4.951178] usb usb3: Manufacturer: Linux 7.1.10-mnt-reform-arm64 xhci-hcd
[ 4.951188] usb usb3: SerialNumber: xhci-hcd.1.auto
[ 4.951731] hub 3-0:1.0: USB hub found
[ 4.951786] hub 3-0:1.0: 1 port detected
[ 4.952138] usb usb4: We don't know the algorithms for LPM for this host, disabling LPM.
[ 4.952277] usb usb4: New USB device found, idVendor=1d6b, idProduct=0003, bcdDevice= 7.01
[ 4.952292] usb usb4: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 4.952303] usb usb4: Product: xHCI Host Controller
[ 4.952312] usb usb4: Manufacturer: Linux 7.1.10-mnt-reform-arm64 xhci-hcd
[ 4.952324] usb usb4: SerialNumber: xhci-hcd.1.auto
[ 4.952852] hub 4-0:1.0: USB hub found
[ 4.952906] hub 4-0:1.0: 1 port detected
[ 5.202917] random: crng init done
[ 5.202981] usb 1-1: new high-speed USB device number 2 using xhci-hcd
[ 5.211261] usb 3-1: new full-speed USB device number 2 using xhci-hcd
[ 5.335578] usb 1-1: New USB device found, idVendor=0451, idProduct=8142, bcdDevice= 1.00
[ 5.335710] usb 1-1: New USB device strings: Mfr=0, Product=0, SerialNumber=1
[ 5.335723] usb 1-1: SerialNumber: 2F010871A4CD
[ 5.356436] usb 3-1: New USB device found, idVendor=1209, idProduct=6d07, bcdDevice= 0.01
[ 5.356476] usb 3-1: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[ 5.356491] usb 3-1: Product: Pocket Reform System Controller 2.0
[ 5.356505] usb 3-1: Manufacturer: MNT
[ 5.356519] usb 3-1: SerialNumber: DE635441939B3634
[ 5.373285] hid: raw HID events driver (C) Jiri Kosina
[ 5.395844] hub 1-1:1.0: USB hub found
[ 5.399901] hub 1-1:1.0: 4 ports detected
[ 5.400678] usbcore: registered new interface driver usbhid
[ 5.400707] usbhid: USB HID core driver
[ 5.463085] usb 2-1: new SuperSpeed USB device number 2 using xhci-hcd
[ 5.488101] usbcore: registered new device driver onboard-usb-dev
[ 5.495589] usb 2-1: New USB device found, idVendor=0451, idProduct=8140, bcdDevice= 1.00
[ 5.495642] usb 2-1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
[ 5.527283] hub 2-1:1.0: USB hub found
[ 5.527412] hub 2-1:1.0: 4 ports detected
[ 5.604574] mc: Linux media interface: v0.10
[ 5.668636] videodev: Linux video capture interface: v2.00
[ 5.738932] usb 1-1.3: new full-speed USB device number 3 using xhci-hcd
[ 5.747185] meson_vdec: module is from the staging directory, the quality is unknown, you have been warned.
[ 5.947605] usb 1-1.3: New USB device found, idVendor=1209, idProduct=6d06, bcdDevice= 0.01
[ 5.947662] usb 1-1.3: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[ 5.947675] usb 1-1.3: Product: Pocket Reform Input 2.0
[ 5.947684] usb 1-1.3: Manufacturer: MNT
[ 5.947693] usb 1-1.3: SerialNumber: DE62549203352A32
[ 6.112919] input: MNT Pocket Reform Input 2.0 Keyboard as /devices/platform/soc@0/32f10100.usb/38100000.usb/xhci-hcd.0.auto/usb1/1-1/1-1.3/1-1.3:1.0/0003:1209:6D06.0001/input/input1
[ 6.251271] input: MNT Pocket Reform Input 2.0 Mouse as /devices/platform/soc@0/32f10100.usb/38100000.usb/xhci-hcd.0.auto/usb1/1-1/1-1.3/1-1.3:1.0/0003:1209:6D06.0001/input/input2
[ 6.251690] input: MNT Pocket Reform Input 2.0 as /devices/platform/soc@0/32f10100.usb/38100000.usb/xhci-hcd.0.auto/usb1/1-1/1-1.3/1-1.3:1.0/0003:1209:6D06.0001/input/input3
[ 6.251921] hid-generic 0003:1209:6D06.0001: input,hidraw0: USB HID v1.11 Keyboard [MNT Pocket Reform Input 2.0] on usb-xhci-hcd.0.auto-1.3/input0
[ 6.378019] SPI driver mnt_sc has no spi_device_id for mntre,system-controller
[ 6.378193] mnt_sc spi1.0: MNT System Controller v4
[ 6.379566] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_probe] start...
[ 6.379605] panel-mnt-pocket-reform 32e60000.dsi.0: DSI burst mode enabled via device tree
[ 6.379774] mnt_sc spi1.0: [mntsc_gpio_set] (set-gpio 0 0)
[ 6.383309] mnt_sc spi1.0: [mntsc_gpio_set] (set-gpio 8 0)
[ 6.386751] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_probe] jdi_panel_add done.
[ 6.386821] samsung-dsim 32e60000.dsi: [drm:samsung_dsim_host_attach [samsung_dsim]] Attached lt070me05000 device (lanes:4 bpp:24 mode-flags:0x13)
[ 6.386923] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_probe] done.
[ 6.599313] reform2_lpc: loading out-of-tree module taints kernel.
[ 6.599365] reform2_lpc: module verification failed: signature and/or required key missing - tainting kernel
[ 6.699669] device-mapper: core: CONFIG_IMA_DISABLE_HTABLE is disabled. Duplicate IMA measurements will not be recorded in the IMA log.
[ 6.699882] device-mapper: uevent: version 1.0.3
[ 6.700349] device-mapper: ioctl: 4.50.0-ioctl (2025-04-28) initialised: dm-devel@lists.linux.dev
[ 16.867510] imx8m-blk-ctrl 32ec0000.blk-ctrl: sync_state() pending due to 32e80000.display-controller
[ 16.867546] imx8m-blk-ctrl 32ec0000.blk-ctrl: sync_state() pending due to 32e30000.dwe
[ 16.867595] imx8mp-blk-ctrl 32fc0000.blk-ctrl: sync_state() pending due to 32fc6000.display-controller
[ 16.867616] imx8m-blk-ctrl 38330000.blk-ctrl: sync_state() pending due to 38310000.video-codec
[ 16.867627] imx8m-blk-ctrl 38330000.blk-ctrl: sync_state() pending due to 38300000.video-codec
[ 16.867766] imx-pgc imx-pgc-domain.4: sync_state() pending due to 38500000.npu
[ 16.867784] imx-pgc imx-pgc-domain.6: sync_state() pending due to 38008000.gpu
[ 16.867800] imx-pgc imx-pgc-domain.9: sync_state() pending due to 38000000.gpu
[ 42.490432] PM: Image not found (code -22)
[ 42.841761] EXT4-fs (dm-2): orphan cleanup on readonly fs
[ 42.841928] EXT4-fs (dm-2): mounted filesystem 08b3c859-272c-4bb7-b1c4-58cd748c93e7 ro with ordered data mode. Quota mode: none.
[ 43.110198] Not activating Mandatory Access Control as /sbin/tomoyo-init does not exist.
[ 43.286950] systemd[1]: Inserted module 'autofs4'
[ 43.674404] systemd[1]: systemd 261.2-1 running in system mode (+PAM +AUDIT +SELINUX +APPARMOR +IMA +IPE +SMACK +SECCOMP +GCRYPT -GNUTLS +OPENSSL +ACL +BLKID +CURL +ELFUTILS +FIDO2 +IDN2 +KMOD +LIBCRYPTSETUP +LIBCRYPTSETUP_PLUGINS +LIBFDISK +PCRE2 +PWQUALITY +P11KIT +QRENCODE +TPM2 +BZIP2 +LZ4 +XZ +ZLIB +ZSTD +BPF_FRAMEWORK +BTF -XKBCOMMON -UTMP +LIBARCHIVE)
[ 43.674528] systemd[1]: Detected architecture arm64.
[ 43.683002] systemd[1]: Hostname set to <cyclone>.
[ 43.966741] systemd[1]: bpf-restrict-fs: Failed to load BPF object: No such process
[ 44.764524] systemd[1]: Queued start job for default target graphical.target.
[ 44.792483] systemd[1]: Created slice system-cups.slice - CUPS Slice.
[ 44.795056] systemd[1]: Created slice system-getty.slice - Slice /system/getty.
[ 44.797416] systemd[1]: Created slice system-modprobe.slice - Slice /system/modprobe.
[ 44.799830] systemd[1]: Created slice system-serial\x2dgetty.slice - Slice /system/serial-getty.
[ 44.802227] systemd[1]: Created slice system-systemd\x2dfsck.slice - Slice /system/systemd-fsck.
[ 44.804017] systemd[1]: Created slice user.slice - User and Session Slice.
[ 44.804686] systemd[1]: Started systemd-ask-password-console.path - Dispatch Password Requests to Console Directory Watch.
[ 44.805157] systemd[1]: Started systemd-ask-password-wall.path - Forward Password Requests to Wall Directory Watch.
[ 44.806132] systemd[1]: Set up automount proc-sys-fs-binfmt_misc.automount - Arbitrary Executable File Formats File System Automount Point.
[ 44.806588] systemd[1]: Expecting device dev-disk-by\x2duuid-b91f5fba\x2deb3b\x2d4713\x2dbfdb\x2dd08c66a7700a.device - /dev/disk/by-uuid/b91f5fba-eb3b-4713-bfdb-d08c66a7700a...
[ 44.806820] systemd[1]: Expecting device dev-mmcblk2p1.device - /dev/mmcblk2p1...
[ 44.807027] systemd[1]: Expecting device dev-ttymxc1.device - /dev/ttymxc1...
[ 44.807254] systemd[1]: Reached target imports.target - Image Downloads.
[ 44.807550] systemd[1]: Reached target nss-user-lookup.target - User and Group Name Lookups.
[ 44.807807] systemd[1]: Reached target slices.target - Slice Units.
[ 44.808501] systemd[1]: Listening on dm-event.socket - Device-mapper event daemon FIFOs.
[ 44.809202] systemd[1]: Listening on lvm2-lvmpolld.socket - LVM2 poll daemon socket.
[ 44.828386] systemd[1]: Listening on rpcbind.socket - RPCbind Server Activation Socket.
[ 44.834118] systemd[1]: Listening on systemd-ask-password.socket - Query the User Interactively for a Password.
[ 44.837968] systemd[1]: Listening on systemd-creds.socket - Credential Encryption/Decryption.
[ 44.843119] systemd[1]: Listening on systemd-factory-reset.socket - Factory Reset Management.
[ 44.843972] systemd[1]: Listening on systemd-hostnamed.socket - Hostname Service Socket.
[ 44.844844] systemd[1]: Listening on systemd-journald-dev-log.socket - Journal Socket (/dev/log).
[ 44.845733] systemd[1]: Listening on systemd-journald.socket - Journal Sockets.
[ 44.851153] systemd[1]: Listening on systemd-mute-console.socket - Console Output Muting Service Socket.
[ 44.852113] systemd[1]: Listening on systemd-udevd-control.socket - udev Control Socket.
[ 44.852813] systemd[1]: Listening on systemd-udevd-kernel.socket - udev Kernel Socket.
[ 44.853584] systemd[1]: Listening on systemd-udevd-varlink.socket - udev Varlink Socket.
[ 44.857933] systemd[1]: Mounting dev-hugepages.mount - Huge Pages File System...
[ 44.862386] systemd[1]: Mounting dev-mqueue.mount - POSIX Message Queue File System...
[ 44.867196] systemd[1]: Mounting sys-kernel-debug.mount - Kernel Debug File System...
[ 44.876257] systemd[1]: Mounting sys-kernel-tracing.mount - Kernel Trace File System...
[ 44.876976] systemd[1]: auth-rpcgss-module.service - Kernel Module supporting RPCSEC_GSS skipped, unmet condition check ConditionPathExists=/etc/krb5.keytab
[ 44.888115] systemd[1]: Starting blk-availability.service - Availability of block devices...
[ 44.900742] systemd[1]: Starting keyboard-setup.service - Set the console keyboard layout...
[ 44.919740] systemd[1]: Starting kmod-static-nodes.service - Create List of Static Device Nodes...
[ 44.950245] systemd[1]: Starting lvm2-monitor.service - Monitoring of LVM2 mirrors, snapshots etc. using dmeventd or progress polling...
[ 44.951074] systemd[1]: modprobe@configfs.service - Load Kernel Module configfs skipped, unmet condition check ConditionKernelModuleLoaded=!configfs
[ 44.990678] systemd[1]: Mounting sys-kernel-config.mount - Kernel Configuration File System...
[ 44.991813] systemd[1]: modprobe@drm.service - Load Kernel Module drm skipped, unmet condition check ConditionKernelModuleLoaded=!drm
[ 45.003471] systemd[1]: Starting modprobe@efi_pstore.service - Load Kernel Module efi_pstore...
[ 45.005501] systemd[1]: modprobe@fuse.service - Load Kernel Module fuse skipped, unmet condition check ConditionKernelModuleLoaded=!fuse
[ 45.012719] systemd[1]: Mounting sys-fs-fuse-connections.mount - FUSE Control File System...
[ 45.031197] systemd[1]: Starting modprobe@nvme_fabrics.service - Load Kernel Module nvme_fabrics...
[ 45.031910] systemd[1]: systemd-fsck-root.service - File System Check on Root Device skipped, unmet condition check ConditionPathExists=!/run/initramfs/fsck-root
[ 45.032120] systemd[1]: systemd-hibernate-clear.service - Clear Stale Hibernate Storage Info skipped, unmet condition check ConditionPathExists=/sys/firmware/efi/efivars/HibernateLocation-8cf2644b-4b0b-428f-9387-6d876050dc67
[ 45.103223] systemd[1]: Starting systemd-journald.service - Journal Service...
[ 45.123210] systemd[1]: Starting systemd-modules-load.service - Load Kernel Modules...
[ 45.143851] systemd[1]: Starting systemd-remount-fs.service - Remount Root and Kernel File Systems...
[ 45.154309] systemd[1]: Starting systemd-udev-load-credentials.service - Load udev Rules from Credentials...
[ 45.161171] systemd[1]: Starting systemd-udev-trigger.service - Coldplug All udev Devices...
[ 45.181930] systemd[1]: Mounted dev-hugepages.mount - Huge Pages File System.
[ 45.187902] systemd[1]: Mounted dev-mqueue.mount - POSIX Message Queue File System.
[ 45.189073] systemd[1]: Mounted sys-kernel-debug.mount - Kernel Debug File System.
[ 45.190291] systemd[1]: Mounted sys-kernel-tracing.mount - Kernel Trace File System.
[ 45.199377] systemd[1]: Finished blk-availability.service - Availability of block devices.
[ 45.211203] systemd[1]: Finished keyboard-setup.service - Set the console keyboard layout.
[ 45.215039] systemd[1]: Finished kmod-static-nodes.service - Create List of Static Device Nodes.
[ 45.221072] systemd[1]: Mounted sys-kernel-config.mount - Kernel Configuration File System.
[ 45.222687] systemd[1]: modprobe@efi_pstore.service: Deactivated successfully.
[ 45.227320] systemd[1]: Finished modprobe@efi_pstore.service - Load Kernel Module efi_pstore.
[ 45.228842] systemd[1]: Mounted sys-fs-fuse-connections.mount - FUSE Control File System.
[ 45.230593] systemd[1]: modprobe@nvme_fabrics.service: Deactivated successfully.
[ 45.234940] systemd[1]: Finished modprobe@nvme_fabrics.service - Load Kernel Module nvme_fabrics.
[ 45.243003] systemd[1]: Starting systemd-tmpfiles-setup-dev-early.service - Create Static Device Nodes in /dev gracefully...
[ 45.263813] systemd[1]: Finished lvm2-monitor.service - Monitoring of LVM2 mirrors, snapshots etc. using dmeventd or progress polling.
[ 45.300251] i2c_dev: i2c /dev entries driver
[ 45.352012] systemd-journald[511]: Collecting audit messages is disabled.
[ 45.412885] systemd[1]: Finished systemd-udev-load-credentials.service - Load udev Rules from Credentials.
[ 45.413352] EXT4-fs (dm-2): re-mounted 08b3c859-272c-4bb7-b1c4-58cd748c93e7 r/w.
[ 45.418333] systemd[1]: Finished systemd-modules-load.service - Load Kernel Modules.
[ 45.427222] systemd[1]: Starting systemd-sysctl.service - Apply Kernel Variables...
[ 45.428591] systemd[1]: Finished systemd-remount-fs.service - Remount Root and Kernel File Systems.
[ 45.436671] systemd[1]: systemd-hwdb-update.service - Rebuild Hardware Database skipped, unmet condition check ConditionNeedsUpdate=/etc
[ 45.436920] systemd[1]: systemd-pstore.service - Platform Persistent Storage Archival skipped, unmet condition check ConditionDirectoryNotEmpty=/sys/fs/pstore
[ 45.446008] systemd[1]: Starting systemd-random-seed.service - Load/Save OS Random Seed...
[ 45.508305] systemd[1]: Finished systemd-tmpfiles-setup-dev-early.service - Create Static Device Nodes in /dev gracefully.
[ 45.512973] systemd[1]: systemd-sysusers.service - Create System Users skipped, no trigger condition checks were met.
[ 45.525163] systemd[1]: Starting systemd-journalctl.socket - Journal Log Access Socket...
[ 45.539228] systemd[1]: Starting systemd-tmpfiles-setup-dev.service - Create Static Device Nodes in /dev...
[ 45.541384] systemd[1]: Listening on systemd-journalctl.socket - Journal Log Access Socket.
[ 45.596371] systemd[1]: Finished systemd-sysctl.service - Apply Kernel Variables.
[ 45.599750] systemd[1]: Finished systemd-random-seed.service - Load/Save OS Random Seed.
[ 45.604383] systemd[1]: Started systemd-journald.service - Journal Service.
[ 45.690456] systemd-journald[511]: Received client request to flush runtime journal.
[ 47.333554] Adding 8388604k swap on /dev/mapper/reformvg-swap. Priority:-1 extents:1 across:8388604k SS
[ 47.966794] EXT4-fs (mmcblk2p1): mounted filesystem c1b214ce-bb62-4a5e-b663-0b32d9127bd0 r/w with ordered data mode. Quota mode: none.
[ 48.186692] audit: type=1400 audit(1787770417.356:2): apparmor="STATUS" operation="profile_load" profile="unconfined" name=4D6F6E676F444220436F6D70617373 pid=616 comm="apparmor_parser"
[ 48.187025] audit: type=1400 audit(1787770417.360:3): apparmor="STATUS" operation="profile_load" profile="unconfined" name="1password" pid=614 comm="apparmor_parser"
[ 48.188521] audit: type=1400 audit(1787770417.360:4): apparmor="STATUS" operation="profile_load" profile="unconfined" name="QtWebEngineProcess" pid=617 comm="apparmor_parser"
[ 48.189946] audit: type=1400 audit(1787770417.360:5): apparmor="STATUS" operation="profile_load" profile="unconfined" name="Discord" pid=615 comm="apparmor_parser"
[ 48.211804] audit: type=1400 audit(1787770417.384:6): apparmor="STATUS" operation="profile_load" profile="unconfined" name="balena-etcher" pid=619 comm="apparmor_parser"
[ 48.218215] audit: type=1400 audit(1787770417.388:7): apparmor="STATUS" operation="profile_load" profile="unconfined" name="buildah" pid=621 comm="apparmor_parser"
[ 48.231813] audit: type=1400 audit(1787770417.404:8): apparmor="STATUS" operation="profile_load" profile="unconfined" name="busybox" pid=622 comm="apparmor_parser"
[ 48.231999] audit: type=1400 audit(1787770417.404:9): apparmor="STATUS" operation="profile_load" profile="unconfined" name="brave" pid=620 comm="apparmor_parser"
[ 48.248125] audit: type=1400 audit(1787770417.420:10): apparmor="STATUS" operation="profile_load" profile="unconfined" name="cam" pid=624 comm="apparmor_parser"
[ 48.254147] audit: type=1400 audit(1787770417.424:11): apparmor="STATUS" operation="profile_load" profile="unconfined" name="ch-checkns" pid=625 comm="apparmor_parser"
[ 48.711744] CSCFG registered etm0
[ 48.711778] coresight etm0: CPU0: etm v4.0 initialized
[ 48.715900] RPC: Registered named UNIX socket transport module.
[ 48.715937] RPC: Registered udp transport module.
[ 48.715945] RPC: Registered tcp transport module.
[ 48.715953] RPC: Registered tcp-with-tls transport module.
[ 48.715961] RPC: Registered tcp NFSv4.1 backchannel transport module.
[ 48.736562] CSCFG registered etm1
[ 48.736581] coresight etm1: CPU1: etm v4.0 initialized
[ 48.737357] CSCFG registered etm2
[ 48.737379] coresight etm2: CPU2: etm v4.0 initialized
[ 48.759301] optee: probing for conduit method.
[ 48.759364] optee: revision 3.17 (0000000098499642)
[ 48.759751] optee: dynamic shared memory is enabled
[ 48.760114] optee: initialized driver
[ 48.761045] CSCFG registered etm3
[ 48.761062] coresight etm3: CPU3: etm v4.0 initialized
[ 48.809965] caam 30900000.crypto: device ID = 0x0a16040100000100 (Era 9)
[ 48.810537] caam 30900000.crypto: job rings = 1, qi = 0
[ 49.383925] dw100 32e30000.dwe: dw100 v4l2 m2m registered as /dev/video0
[ 49.453388] mnt_sc spi1.0: mntsc: couldn't parse response: err undf
[ 49.535073] [drm] Initialized imx-lcdif 1.0.0 for 32e80000.display-controller on minor 0
[ 49.535212] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_get_modes] panel_version: 0
[ 49.539701] mnt_sc spi1.0: mntsc: couldn't parse response: err maxp
[ 49.670257] mnt_sc spi1.0: mntsc: couldn't parse response: err maxp
[ 49.914855] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_prepare] prepared: 0
[ 49.916358] panel-mnt-pocket-reform 32e60000.dsi.0: [mnt_panel_power_on] panel version: 0
[ 50.030963] mnt_sc spi1.0: [mntsc_gpio_set] (set-gpio 0 1)
[ 50.104027] clk: failed to reparent clk_ext2 to audio_pll2_out: -22
[ 50.125491] Bluetooth: Core ver 2.22
[ 50.125616] NET: Registered PF_BLUETOOTH protocol family
[ 50.125633] Bluetooth: HCI device and connection manager initialized
[ 50.125650] Bluetooth: HCI socket layer initialized
[ 50.125658] Bluetooth: L2CAP socket layer initialized
[ 50.125677] Bluetooth: SCO socket layer initialized
[ 50.158980] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_enable] enabled: 0 prepared: 1
[ 50.159031] panel-mnt-pocket-reform 32e60000.dsi.0: [display] init in enable...
[ 50.159053] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_init] enabled: 0 prepared: 1
[ 50.160711] panel-mnt-pocket-reform 32e60000.dsi.0: [mnt_panel_detect_version] read register 12: 0x77
[ 50.160729] panel-mnt-pocket-reform 32e60000.dsi.0: [mnt_panel_detect_version] detected panel_version: 1
[ 50.185911] etnaviv etnaviv: bound 38000000.gpu (ops gpu_ops [etnaviv])
[ 50.209363] etnaviv etnaviv: bound 38008000.gpu (ops gpu_ops [etnaviv])
[ 50.222950] etnaviv etnaviv: bound 38500000.npu (ops gpu_ops [etnaviv])
[ 50.226931] etnaviv-gpu 38000000.gpu: model: GC7000, revision: 6204
[ 50.235053] etnaviv-gpu 38008000.gpu: model: GC520, revision: 5341
[ 50.235249] etnaviv-gpu 38500000.npu: model: GC8000, revision: 8002
[ 50.235272] etnaviv-gpu 38500000.npu: etnaviv has been instantiated on a NPU, for which the UAPI is still experimental
[ 50.236232] [drm] Initialized etnaviv 1.4.0 for etnaviv on minor 1
[ 50.403168] OF: /sound-wwan: Read of boolean property 'simple-audio-card,bitclock-inversion' with a value.
[ 50.409059] hantro-vpu 38300000.video-codec: registered nxp,imx8mm-vpu-g1-dec as /dev/video1
[ 50.412067] hantro-vpu 38310000.video-codec: registered nxp,imx8mq-vpu-g2-dec as /dev/video2
[ 50.432197] Bluetooth: HCI UART driver ver 2.3
[ 50.432240] Bluetooth: HCI UART protocol H4 registered
[ 50.432368] Bluetooth: HCI UART protocol LL registered
[ 50.432373] Bluetooth: HCI UART protocol ATH3K registered
[ 50.432426] Bluetooth: HCI UART protocol Three-wire (H5) registered
[ 50.432889] Bluetooth: HCI UART protocol Intel registered
[ 50.445662] Bluetooth: HCI UART protocol Broadcom registered
[ 50.445745] Bluetooth: HCI UART protocol QCA registered
[ 50.445750] Bluetooth: HCI UART protocol AG6XX registered
[ 50.445781] Bluetooth: HCI UART protocol Marvell registered
[ 50.470977] Bluetooth: hci0: setting up ROME/QCA6390
[ 50.682619] Bluetooth: hci0: Frame reassembly failed (-84)
[ 50.948256] Bluetooth: hci0: QCA Product ID :0x00000008
[ 50.948294] Bluetooth: hci0: QCA SOC Version :0x00000023
[ 50.948314] Bluetooth: hci0: QCA ROM Version :0x00000302
[ 50.948319] Bluetooth: hci0: QCA Patch Version:0x00000111
[ 50.948328] Bluetooth: hci0: QCA controller version 0x00230302
[ 50.948336] Bluetooth: hci0: QCA Downloading qca/rampatch_00230302.bin
[ 51.098053] Bluetooth: hci0: Frame reassembly failed (-84)
[ 51.107778] trusted_key: caam algorithms registered in /proc/crypto
[ 51.109062] caam 30900000.crypto: caam pkc algorithms registered in /proc/crypto
[ 51.109106] caam 30900000.crypto: registering rng-caam
[ 51.109410] caam 30900000.crypto: rng crypto API alg registered prng-caam
[ 51.206926] Bluetooth: hci0: QCA Downloading qca/nvm_00230302.bin
[ 51.404627] Bluetooth: hci0: QCA setup on UART is completed
[ 51.589319] Console: switching to colour frame buffer device 120x37
[ 51.711396] imx-lcdif 32e80000.display-controller: [drm] fb0: imx-lcdifdrmfb frame buffer device
[ 51.717511] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_get_modes] panel_version: 1
[ 51.717786] [drm] Initialized imx-lcdif 1.0.0 for 32fc6000.display-controller on minor 2
[ 51.719581] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_disable] enabled: 1
[ 51.721416] imx-lcdif 32fc6000.display-controller: [drm] Cannot find any crtc or sizes
[ 51.724750] cdc_acm 3-1:1.0: ttyACM0: USB ACM device
[ 51.727648] usbcore: registered new interface driver cdc_acm
[ 51.729488] cdc_acm: USB Abstract Control Model driver for USB modems and ISDN adapters
[ 51.867055] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_unprepare]
[ 51.869364] panel-mnt-pocket-reform 32e60000.dsi.0: [mnt_panel_power_off] panel version: 1
[ 51.982975] mnt_sc spi1.0: [mntsc_gpio_set] (set-gpio 0 1)
[ 52.155681] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_prepare] prepared: 0
[ 52.158559] panel-mnt-pocket-reform 32e60000.dsi.0: [mnt_panel_power_on] panel version: 1
[ 52.251920] cfg80211: Loading compiled-in X.509 certificates for regulatory database
[ 52.265460] Loaded X.509 cert 'benh@debian.org: 577e021cb980e0e820821ba7b54b4961b8b4fadf'
[ 52.270997] mnt_sc spi1.0: [mntsc_gpio_set] (set-gpio 0 1)
[ 52.287011] Loaded X.509 cert 'romain.perier@gmail.com: 3abbc6ec146e09d1b6016ab9d6cf71dd233f0328'
[ 52.296213] Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7'
[ 52.302209] Loaded X.509 cert 'wens: 61c038651aabdcf94bd0ac7ff06c7248db18c600'
[ 52.400512] qcacld2: bad vermagic: kernel tainted.
[ 52.403547] Disabling lock debugging due to kernel taint
[ 52.407195] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_enable] enabled: 0 prepared: 1
[ 52.407220] panel-mnt-pocket-reform 32e60000.dsi.0: [display] init in enable...
[ 52.407224] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_init] enabled: 0 prepared: 1
[ 52.472351] qcacld2: loading driver v4.5.25.57
[ 52.487197] hifDeviceInserted: Dumping clocks (50000000,200000000)
[ 52.491100] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[ 52.494059] Bluetooth: BNEP filters: protocol multicast
[ 52.494083] Bluetooth: BNEP socket layer initialized
[ 52.521640] Bluetooth: MGMT ver 1.23
[ 52.554351] NET: Registered PF_ALG protocol family
[ 52.745443] ol_download_firmware: chip_id:0x5020001 board_id:0x0
[ 52.746379] block nvme0n1: No UUID available providing old NGUID
[ 52.758119] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/bdwlan30.b00 (-2)
[ 52.761241] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/bdwlan30.b00 (-2)
[ 52.771013] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/bdwlan30.b00 (-2)
[ 52.773868] ar6k_wlan mmc1:0001:1: Direct firmware load for qcacld2/bdwlan30.b00 failed with error -2
[ 52.781179] __ol_transfer_bin_file: Failed to get qcacld2/bdwlan30.b00:-2
[ 52.791909] __ol_transfer_bin_file: Trying to load default qcacld2/bdwlan30.bin
[ 52.808080] Board extended Data download address: 0x0
[ 52.834630] __ol_transfer_bin_file: Loading setup file qcacld2/qsetup30.bin
[ 52.834809] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/qsetup30.bin (-2)
[ 52.834919] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/qsetup30.bin (-2)
[ 52.834996] ar6k_wlan mmc1:0001:1: firmware: failed to load qcacld2/qsetup30.bin (-2)
[ 52.835003] ar6k_wlan mmc1:0001:1: Direct firmware load for qcacld2/qsetup30.bin failed with error -2
[ 52.835011] __ol_transfer_bin_file: Failed to get qcacld2/qsetup30.bin:-2
[ 53.077059] imx-dwmac 30bf0000.ethernet end1: Register MEM_TYPE_PAGE_POOL RxQ-0
[ 53.150476] imx-dwmac 30bf0000.ethernet end1: PHY [stmmac-1:07] driver [Micrel KSZ9031 Gigabit PHY] (irq=105)
[ 53.163011] imx-dwmac 30bf0000.ethernet end1: No Safety Features support found
[ 53.170747] imx-dwmac 30bf0000.ethernet end1: IEEE 1588-2008 Advanced Timestamp supported
[ 53.181757] imx-dwmac 30bf0000.ethernet end1: registered PTP clock
[ 53.185064] imx-dwmac 30bf0000.ethernet end1: configuring for phy/rgmii-id link mode
[ 53.229930] NET: Registered PF_QIPCRTR protocol family
[ 53.399817] ar6k_wlan mmc1:0001:1: firmware: failed to load wlan/qcacld2/wlan_mac.bin (-2)
[ 53.402870] ar6k_wlan mmc1:0001:1: firmware: failed to load wlan/qcacld2/wlan_mac.bin (-2)
[ 53.405804] ar6k_wlan mmc1:0001:1: firmware: failed to load wlan/qcacld2/wlan_mac.bin (-2)
[ 53.415756] ar6k_wlan mmc1:0001:1: Direct firmware load for wlan/qcacld2/wlan_mac.bin failed with error -2
[ 53.421274] ------------[ cut here ]------------
[ 53.425961] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiRoam.c:627:33
[ 53.426024] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.426033] CPU: 0 UID: 0 PID: 924 Comm: insmod Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.426043] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.426046] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.426051] Call trace:
[ 53.426054] show_stack+0x20/0x40 (C)
[ 53.426067] dump_stack_lvl+0x60/0x80
[ 53.426075] dump_stack+0x18/0x24
[ 53.426080] ubsan_epilogue+0x10/0x48
[ 53.426088] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.426095] csrUpdateChannelList+0x578/0x828 [qcacld2]
[ 53.426704] csrStart+0x154/0x198 [qcacld2]
[ 53.427254] sme_Start+0x20/0x90 [qcacld2]
[ 53.427772] vos_start+0x90/0x198 [qcacld2]
[ 53.428281] hdd_wlan_startup+0xe5c/0x1948 [qcacld2]
[ 53.428768] ath_hif_sdio_probe+0x368/0x390 [qcacld2]
[ 53.429312] hifEnableFunc.isra.0+0x1c4/0x4b0 [qcacld2]
[ 53.429882] hifDeviceInserted+0x210/0x828 [qcacld2]
[ 53.430449] sdio_bus_probe+0x134/0x1f0
[ 53.430463] really_probe+0xc8/0x3f0
[ 53.430471] __driver_probe_device+0x90/0x1b0
[ 53.430478] driver_probe_device+0x44/0x128
[ 53.430484] __driver_attach+0xd0/0x208
[ 53.430490] bus_for_each_dev+0x84/0xf0
[ 53.430495] driver_attach+0x2c/0x40
[ 53.430501] bus_add_driver+0x124/0x250
[ 53.430506] driver_register+0x70/0x138
[ 53.430512] __sdio_register_driver+0x38/0x78
[ 53.430518] HIFInit+0x80/0xc0 [qcacld2]
[ 53.431108] hif_register_driver+0x74/0xe0 [qcacld2]
[ 53.431689] hdd_hif_register_driver+0x44/0x90 [qcacld2]
[ 53.432259] hdd_module_init+0x104/0xf20 [qcacld2]
[ 53.432832] do_one_initcall+0x5c/0x478
[ 53.432844] do_init_module+0x5c/0x278
[ 53.432851] load_module+0x1d40/0x2698
[ 53.432857] init_module_from_file+0xe8/0x158
[ 53.432863] __arm64_sys_finit_module+0x1f8/0x388
[ 53.432869] invoke_syscall.constprop.0+0xac/0x110
[ 53.432876] el0_svc_common.constprop.0+0x40/0xf0
[ 53.432882] do_el0_svc+0x24/0x40
[ 53.432887] el0_svc+0x40/0x1b0
[ 53.432894] el0t_64_sync_handler+0xa0/0xe8
[ 53.432900] el0t_64_sync+0x198/0x1a0
[ 53.433077] ---[ end trace ]---
[ 53.521112] ------------[ cut here ]------------
[ 53.521121] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiRoam.c:631:55
[ 53.521129] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.521138] CPU: 0 UID: 0 PID: 924 Comm: insmod Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.521147] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.521150] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.521154] Call trace:
[ 53.521158] show_stack+0x20/0x40 (C)
[ 53.521171] dump_stack_lvl+0x60/0x80
[ 53.521178] dump_stack+0x18/0x24
[ 53.521183] ubsan_epilogue+0x10/0x48
[ 53.521190] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.521198] csrUpdateChannelList+0x550/0x828 [qcacld2]
[ 53.521881] csrStart+0x154/0x198 [qcacld2]
[ 53.522396] sme_Start+0x20/0x90 [qcacld2]
[ 53.522826] vos_start+0x90/0x198 [qcacld2]
[ 53.523278] hdd_wlan_startup+0xe5c/0x1948 [qcacld2]
[ 53.523728] ath_hif_sdio_probe+0x368/0x390 [qcacld2]
[ 53.524153] hifEnableFunc.isra.0+0x1c4/0x4b0 [qcacld2]
[ 53.524617] hifDeviceInserted+0x210/0x828 [qcacld2]
[ 53.525054] sdio_bus_probe+0x134/0x1f0
[ 53.525067] really_probe+0xc8/0x3f0
[ 53.525075] __driver_probe_device+0x90/0x1b0
[ 53.525082] driver_probe_device+0x44/0x128
[ 53.525087] __driver_attach+0xd0/0x208
[ 53.525093] bus_for_each_dev+0x84/0xf0
[ 53.525098] driver_attach+0x2c/0x40
[ 53.525103] bus_add_driver+0x124/0x250
[ 53.525109] driver_register+0x70/0x138
[ 53.525114] __sdio_register_driver+0x38/0x78
[ 53.525120] HIFInit+0x80/0xc0 [qcacld2]
[ 53.525542] hif_register_driver+0x74/0xe0 [qcacld2]
[ 53.525969] hdd_hif_register_driver+0x44/0x90 [qcacld2]
[ 53.526398] hdd_module_init+0x104/0xf20 [qcacld2]
[ 53.526820] do_one_initcall+0x5c/0x478
[ 53.526832] do_init_module+0x5c/0x278
[ 53.526841] load_module+0x1d40/0x2698
[ 53.526847] init_module_from_file+0xe8/0x158
[ 53.526853] __arm64_sys_finit_module+0x1f8/0x388
[ 53.526863] invoke_syscall.constprop.0+0xac/0x110
[ 53.526869] el0_svc_common.constprop.0+0x40/0xf0
[ 53.526874] do_el0_svc+0x24/0x40
[ 53.526879] el0_svc+0x40/0x1b0
[ 53.526887] el0t_64_sync_handler+0xa0/0xe8
[ 53.526894] el0t_64_sync+0x198/0x1a0
[ 53.527065] ---[ end trace ]---
[ 53.596242] ------------[ cut here ]------------
[ 53.596252] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiRoam.c:629:33
[ 53.596260] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.596268] CPU: 0 UID: 0 PID: 924 Comm: insmod Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.596278] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.596280] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.596284] Call trace:
[ 53.596287] show_stack+0x20/0x40 (C)
[ 53.596299] dump_stack_lvl+0x60/0x80
[ 53.596306] dump_stack+0x18/0x24
[ 53.596311] ubsan_epilogue+0x10/0x48
[ 53.596319] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.596326] csrUpdateChannelList+0x5a0/0x828 [qcacld2]
[ 53.596930] csrStart+0x154/0x198 [qcacld2]
[ 53.597375] sme_Start+0x20/0x90 [qcacld2]
[ 53.597804] vos_start+0x90/0x198 [qcacld2]
[ 53.598226] hdd_wlan_startup+0xe5c/0x1948 [qcacld2]
[ 53.598656] ath_hif_sdio_probe+0x368/0x390 [qcacld2]
[ 53.599091] hifEnableFunc.isra.0+0x1c4/0x4b0 [qcacld2]
[ 53.599550] hifDeviceInserted+0x210/0x828 [qcacld2]
[ 53.599978] sdio_bus_probe+0x134/0x1f0
[ 53.599991] really_probe+0xc8/0x3f0
[ 53.599999] __driver_probe_device+0x90/0x1b0
[ 53.600006] driver_probe_device+0x44/0x128
[ 53.600011] __driver_attach+0xd0/0x208
[ 53.600017] bus_for_each_dev+0x84/0xf0
[ 53.600022] driver_attach+0x2c/0x40
[ 53.600028] bus_add_driver+0x124/0x250
[ 53.600033] driver_register+0x70/0x138
[ 53.600039] __sdio_register_driver+0x38/0x78
[ 53.600045] HIFInit+0x80/0xc0 [qcacld2]
[ 53.600473] hif_register_driver+0x74/0xe0 [qcacld2]
[ 53.600904] hdd_hif_register_driver+0x44/0x90 [qcacld2]
[ 53.601323] hdd_module_init+0x104/0xf20 [qcacld2]
[ 53.601739] do_one_initcall+0x5c/0x478
[ 53.601751] do_init_module+0x5c/0x278
[ 53.601760] load_module+0x1d40/0x2698
[ 53.601765] init_module_from_file+0xe8/0x158
[ 53.601772] __arm64_sys_finit_module+0x1f8/0x388
[ 53.601778] invoke_syscall.constprop.0+0xac/0x110
[ 53.601784] el0_svc_common.constprop.0+0x40/0xf0
[ 53.601790] do_el0_svc+0x24/0x40
[ 53.601795] el0_svc+0x40/0x1b0
[ 53.601802] el0t_64_sync_handler+0xa0/0xe8
[ 53.601808] el0t_64_sync+0x198/0x1a0
[ 53.601998] ---[ end trace ]---
[ 53.669025] ------------[ cut here ]------------
[ 53.669033] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiRoam.c:649:37
[ 53.671871] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.673316] CPU: 0 UID: 0 PID: 924 Comm: insmod Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.673334] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.673337] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.673341] Call trace:
[ 53.673345] show_stack+0x20/0x40 (C)
[ 53.673361] dump_stack_lvl+0x60/0x80
[ 53.673368] dump_stack+0x18/0x24
[ 53.673373] ubsan_epilogue+0x10/0x48
[ 53.673382] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.673390] csrUpdateChannelList+0x764/0x828 [qcacld2]
[ 53.674011] csrStart+0x154/0x198 [qcacld2]
[ 53.674570] sme_Start+0x20/0x90 [qcacld2]
[ 53.675173] vos_start+0x90/0x198 [qcacld2]
[ 53.675758] hdd_wlan_startup+0xe5c/0x1948 [qcacld2]
[ 53.676349] ath_hif_sdio_probe+0x368/0x390 [qcacld2]
[ 53.676941] hifEnableFunc.isra.0+0x1c4/0x4b0 [qcacld2]
[ 53.677512] hifDeviceInserted+0x210/0x828 [qcacld2]
[ 53.677985] sdio_bus_probe+0x134/0x1f0
[ 53.677998] really_probe+0xc8/0x3f0
[ 53.678005] __driver_probe_device+0x90/0x1b0
[ 53.678012] driver_probe_device+0x44/0x128
[ 53.678017] __driver_attach+0xd0/0x208
[ 53.678023] bus_for_each_dev+0x84/0xf0
[ 53.678028] driver_attach+0x2c/0x40
[ 53.678034] bus_add_driver+0x124/0x250
[ 53.678039] driver_register+0x70/0x138
[ 53.678045] __sdio_register_driver+0x38/0x78
[ 53.678050] HIFInit+0x80/0xc0 [qcacld2]
[ 53.678476] hif_register_driver+0x74/0xe0 [qcacld2]
[ 53.678902] hdd_hif_register_driver+0x44/0x90 [qcacld2]
[ 53.679322] hdd_module_init+0x104/0xf20 [qcacld2]
[ 53.679730] do_one_initcall+0x5c/0x478
[ 53.679743] do_init_module+0x5c/0x278
[ 53.679751] load_module+0x1d40/0x2698
[ 53.679757] init_module_from_file+0xe8/0x158
[ 53.679763] __arm64_sys_finit_module+0x1f8/0x388
[ 53.679772] invoke_syscall.constprop.0+0xac/0x110
[ 53.679779] el0_svc_common.constprop.0+0x40/0xf0
[ 53.679784] do_el0_svc+0x24/0x40
[ 53.679789] el0_svc+0x40/0x1b0
[ 53.679797] el0t_64_sync_handler+0xa0/0xe8
[ 53.679803] el0t_64_sync+0x198/0x1a0
[ 53.679991] ---[ end trace ]---
[ 53.745935] ------------[ cut here ]------------
[ 53.745944] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiRoam.c:651:37
[ 53.745953] index 15 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.745961] CPU: 1 UID: 0 PID: 924 Comm: insmod Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.745971] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.745974] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.745978] Call trace:
[ 53.745981] show_stack+0x20/0x40 (C)
[ 53.745994] dump_stack_lvl+0x60/0x80
[ 53.746001] dump_stack+0x18/0x24
[ 53.746006] ubsan_epilogue+0x10/0x48
[ 53.746013] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.746021] csrUpdateChannelList+0x724/0x828 [qcacld2]
[ 53.746619] csrStart+0x154/0x198 [qcacld2]
[ 53.747164] sme_Start+0x20/0x90 [qcacld2]
[ 53.747704] vos_start+0x90/0x198 [qcacld2]
[ 53.748173] hdd_wlan_startup+0xe5c/0x1948 [qcacld2]
[ 53.748593] ath_hif_sdio_probe+0x368/0x390 [qcacld2]
[ 53.749053] hifEnableFunc.isra.0+0x1c4/0x4b0 [qcacld2]
[ 53.749505] hifDeviceInserted+0x210/0x828 [qcacld2]
[ 53.749932] sdio_bus_probe+0x134/0x1f0
[ 53.749944] really_probe+0xc8/0x3f0
[ 53.749953] __driver_probe_device+0x90/0x1b0
[ 53.749959] driver_probe_device+0x44/0x128
[ 53.749965] __driver_attach+0xd0/0x208
[ 53.749970] bus_for_each_dev+0x84/0xf0
[ 53.749975] driver_attach+0x2c/0x40
[ 53.749980] bus_add_driver+0x124/0x250
[ 53.749986] driver_register+0x70/0x138
[ 53.749992] __sdio_register_driver+0x38/0x78
[ 53.749997] HIFInit+0x80/0xc0 [qcacld2]
[ 53.750440] hif_register_driver+0x74/0xe0 [qcacld2]
[ 53.750926] hdd_hif_register_driver+0x44/0x90 [qcacld2]
[ 53.751400] hdd_module_init+0x104/0xf20 [qcacld2]
[ 53.751854] do_one_initcall+0x5c/0x478
[ 53.751867] do_init_module+0x5c/0x278
[ 53.751876] load_module+0x1d40/0x2698
[ 53.751881] init_module_from_file+0xe8/0x158
[ 53.751888] __arm64_sys_finit_module+0x1f8/0x388
[ 53.751894] invoke_syscall.constprop.0+0xac/0x110
[ 53.751901] el0_svc_common.constprop.0+0x40/0xf0
[ 53.751906] do_el0_svc+0x24/0x40
[ 53.751911] el0_svc+0x40/0x1b0
[ 53.751920] el0t_64_sync_handler+0xa0/0xe8
[ 53.751926] el0t_64_sync+0x198/0x1a0
[ 53.754930] ---[ end trace ]---
[ 53.821346] ------------[ cut here ]------------
[ 53.821409] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12543:41
[ 53.821417] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.821425] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.821435] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.821437] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.821441] Call trace:
[ 53.821445] show_stack+0x20/0x40 (C)
[ 53.821456] dump_stack_lvl+0x60/0x80
[ 53.821462] dump_stack+0x18/0x24
[ 53.821470] ubsan_epilogue+0x10/0x48
[ 53.821477] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.821487] wma_update_channel_list+0x254/0x300 [qcacld2]
[ 53.822102] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 53.822583] VosMCThread+0x210/0x4c8 [qcacld2]
[ 53.823022] kthread+0x134/0x150
[ 53.823035] ret_from_fork+0x10/0x20
[ 53.825034] ---[ end trace ]---
[ 53.851383] ------------[ cut here ]------------
[ 53.851590] target uses HTT version 3.60; host uses 3.28
[ 53.853151] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12546:27
[ 53.854658] *** Warning: host/target HTT versions are different, though compatible!
[ 53.858418] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.860360] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.860379] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.860382] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.860386] Call trace:
[ 53.860389] show_stack+0x20/0x40 (C)
[ 53.860404] dump_stack_lvl+0x60/0x80
[ 53.860411] dump_stack+0x18/0x24
[ 53.860415] ubsan_epilogue+0x10/0x48
[ 53.860424] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.860432] wma_update_channel_list+0x2d0/0x300 [qcacld2]
[ 53.861065] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 53.861676] VosMCThread+0x210/0x4c8 [qcacld2]
[ 53.862236] kthread+0x134/0x150
[ 53.862248] ret_from_fork+0x10/0x20
[ 53.862272] ---[ end trace ]---
[ 53.894077] ------------[ cut here ]------------
[ 53.895900] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12550:27
[ 53.895908] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.895918] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.895929] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.895932] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.895936] Call trace:
[ 53.895939] show_stack+0x20/0x40 (C)
[ 53.895952] dump_stack_lvl+0x60/0x80
[ 53.895959] dump_stack+0x18/0x24
[ 53.895964] ubsan_epilogue+0x10/0x48
[ 53.895972] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.895979] wma_update_channel_list+0x270/0x300 [qcacld2]
[ 53.896595] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 53.897157] VosMCThread+0x210/0x4c8 [qcacld2]
[ 53.897679] kthread+0x134/0x150
[ 53.897691] ret_from_fork+0x10/0x20
[ 53.897747] ---[ end trace ]---
[ 53.932203] ------------[ cut here ]------------
[ 53.932211] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12552:34
[ 53.932218] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.932227] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.932237] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.932240] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.932244] Call trace:
[ 53.932247] show_stack+0x20/0x40 (C)
[ 53.932258] dump_stack_lvl+0x60/0x80
[ 53.932265] dump_stack+0x18/0x24
[ 53.932270] ubsan_epilogue+0x10/0x48
[ 53.932278] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.932286] wma_update_channel_list+0x2f0/0x300 [qcacld2]
[ 53.932891] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 53.933353] VosMCThread+0x210/0x4c8 [qcacld2]
[ 53.933775] kthread+0x134/0x150
[ 53.933787] ret_from_fork+0x10/0x20
[ 53.933797] ---[ end trace ]---
[ 53.968614] ------------[ cut here ]------------
[ 53.968622] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12572:3
[ 53.972366] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 53.972376] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 53.972385] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 53.972389] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 53.972392] Call trace:
[ 53.972395] show_stack+0x20/0x40 (C)
[ 53.972409] dump_stack_lvl+0x60/0x80
[ 53.972416] dump_stack+0x18/0x24
[ 53.972421] ubsan_epilogue+0x10/0x48
[ 53.972429] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 53.972436] wma_update_channel_list+0x2b0/0x300 [qcacld2]
[ 53.973094] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 53.973680] VosMCThread+0x210/0x4c8 [qcacld2]
[ 53.974238] kthread+0x134/0x150
[ 53.974249] ret_from_fork+0x10/0x20
[ 53.974272] ---[ end trace ]---
[ 54.007296] ------------[ cut here ]------------
[ 54.007305] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:12575:3
[ 54.010959] index 1 is out of range for type 'tSirUpdateChanParam [1]'
[ 54.010968] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 54.010978] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 54.010981] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 54.010985] Call trace:
[ 54.010988] show_stack+0x20/0x40 (C)
[ 54.011001] dump_stack_lvl+0x60/0x80
[ 54.011008] dump_stack+0x18/0x24
[ 54.011013] ubsan_epilogue+0x10/0x48
[ 54.011021] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 54.011029] wma_update_channel_list+0x290/0x300 [qcacld2]
[ 54.011688] wma_mc_process_msg+0x158/0x2e98 [qcacld2]
[ 54.012283] VosMCThread+0x210/0x4c8 [qcacld2]
[ 54.012846] kthread+0x134/0x150
[ 54.012857] ret_from_fork+0x10/0x20
[ 54.012973] ---[ end trace ]---
[ 54.077295] Host SW:4.5.25.57, FW:0.0.0.136, HW:QCA93x7_REV1_1
[ 54.086272] ENTER sme_set_btc_coex_dutycycle = 30
[ 54.086303] ENTER sme_set_btc_coex_dutycycle =30
[ 54.086636] ath_hif_sdio: HIF (Atheros/multi-bss)
[ 54.086643] qcacld2: driver loaded in 1608000
[ 54.295278] ------------[ cut here ]------------
[ 54.297302] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiScan.c:5923:95
[ 54.299596] index 8 is out of range for type 'tANI_U8 [8]'
[ 54.301700] CPU: 0 UID: 0 PID: 920 Comm: wpa_supplicant Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 54.301723] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 54.301726] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 54.301731] Call trace:
[ 54.301735] show_stack+0x20/0x40 (C)
[ 54.301752] dump_stack_lvl+0x60/0x80
[ 54.301760] dump_stack+0x18/0x24
[ 54.301765] ubsan_epilogue+0x10/0x48
[ 54.301774] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 54.301782] csrSendMBScanReq+0x764/0x790 [qcacld2]
[ 54.302602] csrScanChannels+0x138/0x190 [qcacld2]
[ 54.303410] csrProcessScanCommand+0x1ec/0x3e0 [qcacld2]
[ 54.304104] smeProcessScanQueue+0x1c8/0x210 [qcacld2]
[ 54.304759] smeProcessCommand+0x1c4/0xbd0 [qcacld2]
[ 54.305418] smeProcessPendingQueue+0x30/0x50 [qcacld2]
[ 54.305991] csrQueueSmeCommand+0x244/0x2e0 [qcacld2]
[ 54.306566] csrScanRequest+0x4c0/0x938 [qcacld2]
[ 54.307187] sme_ScanRequest+0xb8/0x118 [qcacld2]
[ 54.307845] __wlan_hdd_cfg80211_scan+0x490/0x928 [qcacld2]
[ 54.308492] wlan_hdd_cfg80211_scan+0x3c/0x68 [qcacld2]
[ 54.309135] rdev_scan+0x44/0x290 [cfg80211]
[ 54.309521] cfg80211_scan+0x110/0x188 [cfg80211]
[ 54.309697] nl80211_trigger_scan+0x494/0x908 [cfg80211]
[ 54.309848] genl_family_rcv_msg_doit+0xec/0x160
[ 54.309863] genl_rcv_msg+0x214/0x298
[ 54.309869] netlink_rcv_skb+0x70/0x158
[ 54.309875] genl_rcv+0x3c/0x60
[ 54.309881] netlink_unicast+0x1ec/0x300
[ 54.309887] netlink_sendmsg+0x1ac/0x428
[ 54.309893] __sock_sendmsg+0x5c/0xc0
[ 54.309900] ____sys_sendmsg+0x250/0x2c0
[ 54.309906] ___sys_sendmsg+0xb0/0x110
[ 54.309911] __sys_sendmsg+0xa4/0x120
[ 54.309918] __arm64_sys_sendmsg+0x28/0x40
[ 54.309924] invoke_syscall.constprop.0+0xac/0x110
[ 54.309932] el0_svc_common.constprop.0+0x40/0xf0
[ 54.309937] do_el0_svc+0x24/0x40
[ 54.309942] el0_svc+0x40/0x1b0
[ 54.309951] el0t_64_sync_handler+0xa0/0xe8
[ 54.309957] el0t_64_sync+0x198/0x1a0
[ 54.381074] ---[ end trace ]---
[ 54.382692] ------------[ cut here ]------------
[ 54.384260] UBSAN: array-index-out-of-bounds in CORE/MAC/src/pe/lim/limProcessSmeReqMessages.c:1349:51
[ 54.385860] index 8 is out of range for type 'tANI_U8 [8]'
[ 54.387492] CPU: 0 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 54.387517] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 54.387521] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 54.387525] Call trace:
[ 54.387529] show_stack+0x20/0x40 (C)
[ 54.387547] dump_stack_lvl+0x60/0x80
[ 54.387554] dump_stack+0x18/0x24
[ 54.387559] ubsan_epilogue+0x10/0x48
[ 54.387568] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 54.387577] __limProcessSmeScanReq+0xf34/0x1030 [qcacld2]
[ 54.388374] limProcessSmeReqMessages+0x12ec/0x31d8 [qcacld2]
[ 54.389121] limProcessNormalHddMsg+0xc4/0x138 [qcacld2]
[ 54.389813] limProcessMessages+0xaa8/0x2170 [qcacld2]
[ 54.390490] limMessageProcessor+0x120/0x1e8 [qcacld2]
[ 54.391169] peProcessMessages+0x4c/0x88 [qcacld2]
[ 54.391878] VosMCThread+0xf0/0x4c8 [qcacld2]
[ 54.392409] kthread+0x134/0x150
[ 54.392424] ret_from_fork+0x10/0x20
[ 54.423328] ---[ end trace ]---
[ 54.425078] ------------[ cut here ]------------
[ 54.426770] UBSAN: array-index-out-of-bounds in CORE/SERVICES/WMA/wma.c:11908:41
[ 54.428586] index 8 is out of range for type 'tANI_U8 [8]'
[ 54.430346] CPU: 2 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 54.430364] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 54.430367] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 54.430371] Call trace:
[ 54.430374] show_stack+0x20/0x40 (C)
[ 54.430389] dump_stack_lvl+0x60/0x80
[ 54.430396] dump_stack+0x18/0x24
[ 54.430401] ubsan_epilogue+0x10/0x48
[ 54.430408] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 54.430416] wma_get_buf_start_scan_cmd+0x944/0x9c0 [qcacld2]
[ 54.431061] wma_start_scan+0x88/0x2f8 [qcacld2]
[ 54.431682] wma_mc_process_msg+0x140/0x2e98 [qcacld2]
[ 54.432321] VosMCThread+0x210/0x4c8 [qcacld2]
[ 54.432936] kthread+0x134/0x150
[ 54.432952] ret_from_fork+0x10/0x20
[ 54.463721] ---[ end trace ]---
[ 57.275130] ------------[ cut here ]------------
[ 57.275163] UBSAN: array-index-out-of-bounds in CORE/SME/src/csr/csrApiScan.c:5665:42
[ 57.275187] index 2 is out of range for type 'tLimScanChn [1]'
[ 57.275200] CPU: 2 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 57.275210] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 57.275212] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 57.275216] Call trace:
[ 57.275219] show_stack+0x20/0x40 (C)
[ 57.275231] dump_stack_lvl+0x60/0x80
[ 57.275238] dump_stack+0x18/0x24
[ 57.275242] ubsan_epilogue+0x10/0x48
[ 57.275250] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 57.275257] csrScanAgeResults+0x190/0x1a0 [qcacld2]
[ 57.275860] csrScanSmeScanResponse+0x214/0x300 [qcacld2]
[ 57.276447] csrScanningStateMsgProcessor+0x44/0x3f0 [qcacld2]
[ 57.276980] csrMsgProcessor+0x1cc/0x4d0 [qcacld2]
[ 57.277476] sme_ProcessMsg+0xbbc/0xd38 [qcacld2]
[ 57.277953] VosMCThread+0x1e4/0x4c8 [qcacld2]
[ 57.278424] kthread+0x134/0x150
[ 57.278437] ret_from_fork+0x10/0x20
[ 57.278707] ---[ end trace ]---
[ 57.427371] ------------[ cut here ]------------
[ 57.427414] UBSAN: array-index-out-of-bounds in CORE/SME/src/ccm/ccmApi.c:421:40
[ 57.427445] index 1 is out of range for type 'tANI_U32 [1]'
[ 57.427459] CPU: 3 UID: 0 PID: 954 Comm: VosMCThread Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 57.427469] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 57.427472] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 57.427475] Call trace:
[ 57.427479] show_stack+0x20/0x40 (C)
[ 57.427492] dump_stack_lvl+0x60/0x80
[ 57.427500] dump_stack+0x18/0x24
[ 57.427505] ubsan_epilogue+0x10/0x48
[ 57.427512] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 57.427520] ccmCfgCnfMsgHandler+0x64/0x330 [qcacld2]
[ 57.428111] sme_ProcessMsg+0xa88/0xd38 [qcacld2]
[ 57.428667] VosMCThread+0x1e4/0x4c8 [qcacld2]
[ 57.429210] kthread+0x134/0x150
[ 57.429222] ret_from_fork+0x10/0x20
[ 57.429269] ---[ end trace ]---
[ 57.538476] ------------[ cut here ]------------
[ 57.538502] UBSAN: array-index-out-of-bounds in CORE/CLD_TXRX/HTT/htt_t2h.c:885:35
[ 57.538511] index 1 is out of range for type 'A_UINT16 [1]'
[ 57.538521] CPU: 1 UID: 0 PID: 1002 Comm: AR6K RxCompleti Tainted: GF C OE 7.1.10-mnt-reform-arm64 #1 PREEMPTLAZY Debian 7.1.10-1+reform20260826T130932Z
[ 57.538531] Tainted: [F]=FORCED_MODULE, [C]=CRAP, [O]=OOT_MODULE, [E]=UNSIGNED_MODULE
[ 57.538534] Hardware name: MNT Pocket Reform with i.MX8MP Module (DT)
[ 57.538538] Call trace:
[ 57.538541] show_stack+0x20/0x40 (C)
[ 57.538553] dump_stack_lvl+0x60/0x80
[ 57.538559] dump_stack+0x18/0x24
[ 57.538564] ubsan_epilogue+0x10/0x48
[ 57.538571] __ubsan_handle_out_of_bounds+0x90/0xc0
[ 57.538578] htt_t2h_msg_handler+0x698/0x7c0 [qcacld2]
[ 57.539107] DoRecvCompletion.part.0+0x88/0x140 [qcacld2]
[ 57.539547] HTCRxCompletionHandler+0x62c/0x848 [qcacld2]
[ 57.539955] processHdrAndRxComp.part.0.isra.0+0x9c/0xd0 [qcacld2]
[ 57.540358] processHdrAndRxComp.constprop.0+0x5c/0x110 [qcacld2]
[ 57.540756] rx_completion_task+0x474/0x520 [qcacld2]
[ 57.541173] kthread+0x134/0x150
[ 57.541184] ret_from_fork+0x10/0x20
[ 57.541194] ---[ end trace ]---
[ 57.874490] Bluetooth: RFCOMM TTY layer initialized
[ 57.874564] Bluetooth: RFCOMM socket layer initialized
[ 57.874595] Bluetooth: RFCOMM ver 1.11
[ 60.155894] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_get_modes] panel_version: 1
[ 64.771064] rfkill: input handler disabled
[ 65.870978] systemd-journald[511]: Time jumped backwards, rotating.
[ 82.286397] rfkill: input handler enabled
[ 84.395573] panel-mnt-pocket-reform 32e60000.dsi.0: [jdi_panel_get_modes] panel_version: 1
[ 90.066190] rfkill: input handler disabled
(My unit is bone stock - v1 display etc. MNT unstable LUKS install on NVMe. Disregard the failed attempts to check the bootloader version; my ISP doesn’t seem to like source.mnt.re for some strange reason. It succeeds at work!)
I’m aware of various post-update display issue topics already on the forum, but as far as I can tell none of them are specific to the LUKS prompt; I have no problems once booted up aside from the occasional flicker on screen wakes ( maybe the issue Lucie drafted a fix for described here?) Do correct me if this would be better as a reply to one of the existing conversations!
The upcoming Quasar does look quite appealing given how anemic the i.MX8MQ has been for me - even before GNOME, multitasking under sway was something of a pain - so I’d love to figure this out before committing to one. I’ve got a list of other remedial things to look at (replacing my original backplate with the WiFi-friendly version, figuring out why GNOME won’t let me change my user avatar, maybe adding a more convenient physical switch to prevent power loss overnight) but as this is the first step in the chain I thought I’d tackle it first!
